5  Building Reproducible Pipelines with Nix and {rixpress}

What you’ll have learned by the end of the chapter: how to orchestrate a fully reproducible, polyglot analytical pipeline using Nix as a build automation tool, and why this is a fundamentally more robust approach than using computational notebooks or other common workflow tools.

5.1 Introduction: From Scripts and Notebooks to Pipelines

So far, we have learned about the 3 main necessary pillars for building reproducible pipelines:

  1. Define Reproducible Environments with Nix and {rix} to ensure everyone uses the exact same versions of R, Python, and all system-level dependencies.
  2. Manage Reproducible History with Git to track every change to our code and collaborate effectively.
  3. Write Reproducible Logic with Functional Programming to create clean, testable, and predictable functions.

The last pillar is orchestration.

How do we take our collection of functions and data files and run them in the correct order to produce our final data product? This problem of managing computational workflows is not new, and a whole category of build automation tools has been created to solve it.

The original solution to this problem, dating back to the 1970s, is make. Created by Stuart Feldman at Bell Labs in 1976, make was born out of frustration. Feldman, working on his Fortran programs, was tired of the tedious and error-prone process of manually re-compiling only the necessary parts of his code after making a change. He designed make to read a Makefile that describes the dependency graph of a project. You tell it that report.pdf depends on plot.png. If you change the code that generates plot.png, make is smart enough to only re-run the steps needed to rebuild the plot and the final report. General-purpose tools like waf follow a similar philosophy.

The strength of these tools is their language-agnosticism, but their weakness is that they only track files and know nothing about the software environment needed to create those files. Another limitaton of these generic tools is that they are file-centric. This means that you are responsible for manually handling all input and output. Your first script must explicitly save its result as data.csv, and your second script must explicitly load data.csv. This adds boilerplate code and creates a new surface for errors.

This is where a specialized tool like R’s {targets} package shines. {targets} tracks dependencies between R objects directly, not just files. When you pass a data frame from one step to the next, {targets} automatically handles the serialization for you (serialization is the process of saving an object into a binary to disk) behind the scenes and loads it back when needed. This is a massive ergonomic improvement, allowing you to think in terms of data objects, not file paths.

The Python ecosystem, while rich in tools, lacks a single, dominant tool that offers the same lightweight, object-centric feel as {targets} for everyday analysis. Tools like Snakemake are powerful but often follow the make model of file-based I/O. Others like Luigi or Airflow are typically used for large-scale data engineering but can be overkill for a typical analytical project. This gap highlights the need for a solution that combines an ergonomic, object-passing interface with robust reproducibility.

Furthermore, all these tools, from make to {targets} to Airflow, separate workflow management from environment management. You use one tool to run the pipeline and another (like conda, Docker, or {renv}) to set up the software. But what if we could use a single, declarative system to manage both?

This is why we will also be using Nix for build automation. Nix is not just a package manager; it is a full-fledged build system. When Nix builds a pipeline, it controls the entire dependency graph, from your input data files all the way down to the C compiler used to build R itself. It unifies the “what to run and when” problem with the “what tools to use” problem into a single, cohesive framework.

However, writing build instructions directly in the Nix language can be complex. This is where {rixpress} comes in. It provides a user-friendly R interface, heavily inspired by {targets}, that lets us define our pipeline in familiar R code. {rixpress} then translates this into the necessary Nix expressions for us. We get the ergonomic, object-passing feel of {targets} with the unparalleled, bit-for-bit reproducibility of the Nix build system. It is the perfect tool to complete our reproducible workflow.

5.2 Our First Polyglot Pipeline

Let’s start with a simple pipeline. Our goal will be to read the mtcars dataset, perform some initial filtering in Python with {polars}, pass the result to R for further manipulation with {dplyr}, and finally compile a Quarto document that presents the results.

First, let’s create a new project directory. Inside, we’ll bootstrap our project. If you’re in a terminal, you can get a temporary shell with the necessary tools by running:

nix-shell --expr "$(curl -sl https://raw.githubusercontent.com/ropensci/rix/main/inst/extdata/default.nix)"

Once inside this temporary shell, start R and run:

rixpress::rxp_init()

This handy function creates two essential plain text files: gen-env.R and gen-pipeline.R.

5.2.1 Step 0: Use Git

This might be the right time to start a Git repository. Either start by creating an empty project on GitHub, or start from your command line, locally:

git init

5.2.2 Step 1: Defining the Environment

Open gen-env.R. This is where we use {rix} to define the tools our pipeline needs.

# In gen-env.R
library(rix)

# Define execution environment for our polyglot pipeline
rix(
  date = "2025-06-02",
  r_pkgs = c("dplyr", "quarto", "reticulate", "jsonlite"),
  py_conf = list(
    py_version = "3.13",
    py_pkgs = c("polars", "pyarrow", "pandas")
  ),
  git_pkgs = list(
    package_name = "rixpress",
    repo_url = "https://github.com/b-rodrigues/rixpress",
    commit = "HEAD"
  ),
  ide = "none",
  project_path = ".",
  overwrite = TRUE
)

Run this script (source("gen-env.R")) to generate the default.nix file that describes our complete environment. Now, exit the temporary shell, build your project environment with nix-build, and enter it with nix-shell.

5.2.3 Step 2: Defining the Pipeline

Now, open gen-pipeline.R. This plain text file is where we’ll define the actual pipeline. {rixpress} offers several ways to pass data between languages.

A pipeline is a list of derivations. A derivation is defined using functions such as rxp_r(), rxp_py(), etc. Most of the time, we start by importing data. In this case, we will be importing a .csv file (which you can download here and save it in the data/ folder) using polars:

# In gen-pipeline.R
library(rixpress)

list(
  rxp_py_file(
    name = mtcars_pl,
    path = "data/mtcars.csv",
    read_function = "lambda x: polars.read_csv(x, separator='|')"
  ),
  ...
)

We use the rxp_py_file() function to define a derivation that reads in the .csv file using the read_csv() function from polars. When importing data using rxp_py_file() or (rxp_r_file()), the read_function argument must be a function of a single argument, the path to the data.

Next, we want to filter the dataset:

# In gen-pipeline.R
library(rixpress)

list(
  rxp_py_file(
    name = mtcars_pl,
    path = 'data/mtcars.csv',
    read_function = "lambda x: polars.read_csv(x, separator='|')"
  ),
  # Note: polars must be converted to pandas for reticulate
  rxp_py(
    name = mtcars_pl_am,
    py_expr = "mtcars_pl.filter(polars.col('am') == 1).to_pandas()"
  ),
  ...

The next derivation is defined using rxp_py() which runs Pyton code. As you can see, the py_expr argument is literal Python code, where polars is used to filter data and then convert the result to a pandas data frame.

To pass data to R, we have two methods available.

5.2.3.1 Method 1: Using Language-Specific Converters

The rxp_r2py() and rxp_py2r() functions are convenient wrappers that use the {reticulate} package behind the scenes to convert objects:

  rxp_py2r(
    name = mtcars_am_r,
    expr = mtcars_pl_am
  ),
  ...

This converts the mtcars_pl_am data frame (which is a pandas data frame) into an R data frame using the R package {reticulate}.

We can then continue with an R derivation:

  rxp_r(
    name = mtcars_head,
    expr = head(mtcars_am_r)
  ),
  ...

This works well, but it tightly couples your pipeline to {reticulate}’s conversion capabilities, which in some cases could be overkill.

5.2.3.2 Method 2: A lighter Approach with Universal Data Formats

A lighter and language-agnostic approach is to use a universal data format like JSON. This makes your pipeline more modular, as any language that can read and write JSON could be added in the future. {rixpress} supports this via the serialize_function and unserialize_function arguments.

Let’s rewrite our pipeline to use JSON. First, we need simple helper functions in our project.

Create a script called functions.py that will contain all the Python helper functions we might need. In it, add:

# A function to save a polars DataFrame to a JSON file
def serialize_to_json(pl_df, path):
    with open(path, 'w') as f:
        f.write(pl_df.write_json())

Do the same for R functions, in functions.R:

# Just aliasing head for demonstration
my_head <- head

Now, we can update gen-pipeline.R to use these helpers:

library(rixpress)

list(
  ....

  rxp_py(
    name = mtcars_pl_am,
    py_expr = "mtcars_pl.filter(polars.col('am') == 1)",
    additional_files = "functions.py",
    serialize_function = "serialize_to_json" # Use our Python helper
  ),

  rxp_r(
    name = mtcars_head,
    expr = my_head(mtcars_pl_am),
    additional_files = "functions.R",
    unserialize_function = "jsonlite::fromJSON" # Use R's jsonlite
  ),
  ...
)

This approach works well in simple cases like passing data frames between languages, but may not work for more complex objects for which {reticulate} may have specialized code for conversion.

5.2.4 Step 3: Building and Inspecting the Pipeline

The complete pipeline will look like this:

library(rixpress)

list(
  rxp_py_file(
    name = mtcars_pl,
    path = 'data/mtcars.csv',
    read_function = "lambda x: polars.read_csv(x, separator='|')"
  ),
  # Note: polars must be converted to pandas for reticulate
  rxp_py(
    name = mtcars_pl_am,
    py_expr = "mtcars_pl.filter(polars.col('am') == 1).to_pandas()"
  ),
  rxp_py(
    name = mtcars_pl_am,
    py_expr = "mtcars_pl.filter(polars.col('am') == 1)",
    additional_files = "functions.py",
    serialize_function = "serialize_to_json" # Use our Python helper
  ),

  rxp_r(
    name = mtcars_head,
    expr = my_head(mtcars_pl_am),
    additional_files = "functions.R",
    unserialize_function = "jsonlite::fromJSON" # Use R's jsonlite
  ),
) |>
  rixpress()

The very last function, rixpress() takes a list of derivations as input and will translate the list of derivations into a pipeline.nix file and instruct Nix to build the entire pipeline. Once it’s done, you can use rxp_inspect() to check which artifacts where built, and you can easily access the any of them:

# Check out all artifacts
rxp_inspect()

# Load the mtcars_head data frame into your R session
rxp_load("mtcars_head")

# You can now inspect it
head(mtcars_head)

You can also only generate the required code, but not run the pipeline yet, by setting build = FALSE in rixpress().

5.3 Caching

First, visualize your pipeline’s dependency graph:

# You'll need to firts generate the required files by running
# `rixpress(...)` or `rixpress(..., build = FALSE)` first
# Then you can visualize the graph
rxp_ggdag()

This will show you a clear, unambiguous graph of your workflow.

Now, modify a step. Open gen-pipeline.R and change the my_head function in functions.R to use tail() for example. Save the file and re-run rixpress(). Nix will detect that the data loading and Python filtering steps are unchanged and instantly use the cached results from the /nix/store/. It will only re-build the final R step that was affected by the change.

This is the incredible power of a proper build automation tool. The cognitive load of tracking what to re-run is gone. You are free to experiment, confident that the tool will efficiently and correctly rebuild only what is necessary.

5.4 Debugging and Working with Build Logs

But what happens to the old results? What if you want to compare the head() version of your data to the tail() version? This is where {rixpress}’s build logging becomes a superpower.

Every time you run rixpress(), a timestamped log of that specific build is saved in the _rixpress/ directory. This is like having a Git history for your pipeline’s outputs.

You can list all the past builds you’ve run:

rxp_list_logs()
#>                                                          filename   modification_time
#> 1 build_log_20250602_143015_a1b2c3d4e5f6g7h8i9j0k1l2m3n4o5p6.rds 2025-06-02 14:30:15
#> 2 build_log_20250602_142500_z9y8x7w6v5u4t3s2r1q0p9o8n7m6l5k4.rds 2025-06-02 14:25:00

Let’s say the first log (...a1b2c3d...) is our new tail() run, and the second (...z9y8x7w...) is our original head() run. You can now pull the artifact from the old run directly into your current session for comparison:

# Load the result from the MOST RECENT build
new_result <- rxp_read("mtcars_head")

# Load the result from the PREVIOUS build by matching part of its log name
old_result <- rxp_read("mtcars_head", which_log = "z9y8x")

# Now you can compare them!
new_result
old_result

This is an incredibly powerful debugging and validation tool. You can go back in time to inspect the state of any output from any previous pipeline run, as long as it’s still in the Nix store. This provides a safety net and traceability that is simply absent in a notebook-based workflow.

5.5 Running Someone Else’s Pipeline: The Ultimate Test of Reproducibility

Imagine a collaborator wants to run your pipeline. If you had sent them a Jupyter notebook, they would face a series of questions: “Which version of Python did you use? What packages do I need? In what order do I run the cells? What is this variable that’s used but never defined?”

With our Nix-based workflow, the process is radically simpler and more robust. All they need to do is:

  1. git clone your repository (which, unlike a notebook, has a clean, readable history).
  2. Run nix-build, then nix-shell in the project directory.
  3. Start an R session, and build the pipeline by running the gen-pipeline.R script, or by running rxp_make().

That’s it. Nix reads your default.nix and pipeline.nix files and builds the exact same environment and the exact same data product, bit-for-bit. It solves all the problems we identified with other approaches: it controls the language versions, the operating system libraries, and all dependencies in one unified, declarative system.

You now have the knowledge to build robust, efficient, polyglot, and truly reproducible analytical pipelines. By abandoning the chaos of notebooks for production work and embracing the structured, automatable world of plain text files and build automation, your work becomes more reliable, more scalable, and fundamentally more scientific.
